📖 Project Overview

One-KVM is a DIY IP-KVM solution built upon the open-source PiKVM project. It uses cost-effective hardware to provide BIOS-level remote management for servers and workstations.

Use Cases

• Home lab management – Remotely manage servers and development devices
• Server maintenance – Perform system maintenance without physical access
• System recovery – Troubleshoot boot and BIOS/UEFI issues remotely

📊 Features

Core Capabilities

Feature	Description	Benefit
Non-intrusive	No software/driver required on the target machine	OS-agnostic; access BIOS/UEFI
Cost-effective	Leverages affordable hardware (TV boxes, dev boards)	Lower cost for KVM-over-IP
Extendable	Added utilities on top of PiKVM	Docker, recording, Chinese UI
Deployment	Supports Docker and prebuilt images	Preconfigured images for specific devices

Limitations

This project is maintained by an individual with limited resources and no commercial plan.

• No built-in free NAT punching/tunneling service
• No 24×7 technical support
• No guarantee on stability/compliance; use at your own risk
• User experience is optimized, but basic technical skills are still required

Feature Comparison

💡 Note: The table below compares One-KVM with other PiKVM-based projects for reference only. If there are omissions or inaccuracies, please open an issue to help improve it.

Feature	One-KVM	PiKVM	ArmKVM	BLIKVM
Simplified Chinese WebUI	✅	❌	✅	✅
Remote video stream	MJPEG/H.264	MJPEG/H.264	MJPEG/H.264	MJPEG/H.264
H.264 encoding	CPU	GPU	Unknown	GPU
Remote audio	✅	✅	✅	✅
Remote mouse/keyboard	OTG/CH9329	OTG/CH9329/Pico/Bluetooth	OTG	OTG
VNC control	✅	✅	✅	✅
ATX power control	GPIO/USB relay	GPIO	GPIO	GPIO
Virtual drive mounting	✅	✅	✅	✅
Web terminal	✅	✅	✅	✅
Docker deployment	✅	❌	❌	❌
Commercial offering	❌	✅	✅	✅

⚡ Quick Start

Method 1: Docker (Recommended)

The Docker variant supports OTG or CH9329 as virtual HID and runs on Linux for amd64/arm64/armv7.

One-liner Script

curl -sSL https://one-kvm.mofeng.run/quick_start.sh -o quick_start.sh && bash quick_start.sh

Manual Deployment

It is recommended to use the --net=host network mode for better WOL functionality and WebRTC communication support.

Docker host network mode:

Port 8080: HTTP Web service
Port 4430: HTTPS Web service
Port 5900: VNC service
Port 623: IPMI service
Ports 20000-40000: WebRTC communication port range for low-latency video
Port 9 (UDP): Wake-on-LAN (WOL)

Docker host mode:

Using OTG as virtual HID:

sudo docker run --name kvmd -itd --privileged=true \
    -v /lib/modules:/lib/modules:ro -v /dev:/dev \
    -v /sys/kernel/config:/sys/kernel/config -e OTG=1 \
    --net=host \
    silentwind0/kvmd

Using CH9329 as virtual HID:

sudo docker run --name kvmd -itd \
    --device /dev/video0:/dev/video0 \
    --device /dev/ttyUSB0:/dev/ttyUSB0 \
    --net=host \
    silentwind0/kvmd

Docker bridge mode:

Using OTG as virtual HID:

sudo docker run --name kvmd -itd --privileged=true \
    -v /lib/modules:/lib/modules:ro -v /dev:/dev \
    -v /sys/kernel/config:/sys/kernel/config -e OTG=1 \
    -p 8080:8080 -p 4430:4430 -p 5900:5900 -p 623:623 \
    silentwind0/kvmd

Using CH9329 as virtual HID:

sudo docker run --name kvmd -itd \
    --device /dev/video0:/dev/video0 \
    --device /dev/ttyUSB0:/dev/ttyUSB0 \
    -p 8080:8080 -p 4430:4430 -p 5900:5900 -p 623:623 \
    silentwind0/kvmd

Method 2: Flash Prebuilt One-KVM Images

Preconfigured images are provided for specific hardware platforms to simplify deployment and enable out-of-the-box experience.

Download

GitHub:

• GitHub Releases: https://github.com/mofeng-git/One-KVM/releases

Other mirrors:

• No-login mirror: https://pan.huang1111.cn/s/mxkx3T1
• Baidu Netdisk: https://pan.baidu.com/s/166-2Y8PBF4SbHXFkGmFJYg?pwd=o9aj (code: o9aj)

Supported Hardware Platforms

Firmware	Codename	Hardware	Latest	Status
OneCloud	Onecloud	USB capture card, OTG	241018	✅
CumeBox 2	Cumebox2	USB capture card, OTG	241004	✅
Vmare	Vmare-uefi	USB capture card, CH9329	241004	✅
VirtualBox	Virtualbox-uefi	USB capture card, CH9329	241004	✅
s905l3a Generic	E900v22c	USB capture card, OTG	241004	✅
Chainedbox	Chainedbox	USB capture card, OTG	241004	✅
Loongson 2K0300	2k0300	USB capture card, CH9329	241025	✅

🤝 Contributing

Contributions of all kinds are welcome!

How to Contribute

1. Fork this repo
2. Create a feature branch: git checkout -b feature/AmazingFeature
3. Commit your changes: git commit -m 'Add some AmazingFeature'
4. Push to the branch: git push origin feature/AmazingFeature
5. Open a Pull Request

Report Issues

If you find bugs or have suggestions:

1. Open an issue via GitHub Issues
2. Provide detailed error logs and reproduction steps
3. Include your hardware and system information

Sponsorship

This project builds upon many great open-source projects and requires considerable time for testing and maintenance. If you find it helpful, consider supporting via Afdian.
